Configured Specifications of EGH20CA-CM-ADZ-2R220MM/20-20：
|
Rail Length L |
220mm/20-20 |
Block Type |
[square] Standard Block |
|
Assembly Height H |
28 |
Nominal Part Number |
20 |
|
Rail Type |
Standard Rail |
Set / Single Item |
2blocks plus 1 rail |
|
Preload |
[Clearance] Normal Clearance |
Accuracy Standards |
Standard Grade |
|
Material |
GCR15 bearing steel |
Ball Arrangement |
Medium, Heavy Load Type |
|
No. of Blocks |
2 |
Rolling Element |
Ball |
|
Applicable Linear Guide |
EGH20CA-CM-ADZ |
Block Material (Surface Treatment) |
/ |
|
Rail Material (Surface Treatment) |
Black chrome plating |
Operating Temperature |
-20 to 80°C |
Product Description：
EGH linear guide is a guide rail system for high-precision linear motion, with a compact design and high rigidity. It achieves low friction and smooth motion by rolling the ball between the slider and the guide rail. It is often used in equipment that needs to save space, such as automation equipment and precision machinery. EGH linear guide is suitable for various industrial applications due to its lightness, stability and long life.
Key Features：
High Cost-Effectiveness: While ensuring superior quality, the pricing is affordable, effectively controlling procurement costs for users.
Comprehensive Specifications: Offers a variety of sizes to flexibly match installation needs from micro-devices to heavy-duty models.
Stable and Durable: Utilizes high-quality materials and precision manufacturing processes, making it wear-resistant and impact-resistant, maintaining long-term accuracy and stable operation even under harsh conditions such as dust and vibration.
Application Areas：
Widely applicable to various automated equipment and precision machinery, such as:
- CNC machine tools (machining centers, milling and turning machines)
- 3D printing and additive manufacturing equipment
- Measuring instruments, optical inspection platforms
- Semiconductor packaging equipment, pick-and-place machines
- Packaging machinery, material handling lines, and other linear motion scenarios.
Additional Advantages
Maintenance-free option available, reducing the frequency of later maintenance; Compatible with mainstream international installation equipment, facilitating replacement and upgrades.
Date sheet:
